Introduction :
Potato|Cassava Starch Processing Machine is also suitable for Yam/Sweet Potato starch processing.
Potato Starch Making Process is Cleaning and Peeling--Grinding--Dewatering--Drying--Screening—Packaging. In the crushing section, our Curved Mesh Crusher with national patent is used in grinding and screening setions, it smash the material after multi-level filtering, multi-stage extrusion by a unique processing cycle, with low energy consumption, high starch extraction rate and good quality.
The whole production line machines includes: Feeding Machine; Washing Machine; Grinder; Starch extraction Machine; Desander; Starch refine system; Drying Machine; Packaging Machine for Flour.
Plant:
This project covers an area of about 400 square equipment, the plant generally is not small than 1,000-square
Power:
380 volts, 3 phases, 50 Hertz, the largest floating voltage 6% and 4% of the maximum frequency of floating.
The installed capacity:
About 180KW, the actual consumption: about 150KW
Water:
The extraction Section 15-20 cubic / hour, at room temperature, in line with the drinking water standard.Section 10 cubic cleansing / hour, can be part of the cycle, can also be used latter water Dryer, 1-2 tons of user-owned boiler, hot stove can also be used in our plant.
| ITEM | Name and model | Unit | Quantity | Power | REMARK |
| First | Clean machine | ||||
| 1 | Water power convey groove | ||||
| 2 | Cleaning machine Ⅰ | set | 1 | 3 |
Carbon steel |
| 3 | Cleaning machine Ⅱ | Set | 1 | 1.5 |
Carbon steel |
| 4 | Potato cleaning convey machine | set | 1 | 3 |
Carbon steel |
| Second | Extraction and refining section | ||||
| 1 |
extrusion-milling machine (making powder ) |
Set | 1 | 30 |
Carbon steel |
| 2 | Fine filter (latex) | Set | 2 | 3 |
Carbon steel |
| 3 | Starch micro-filtration machine | Set | 1 | 1 | |
| 4 | Desanding machine | Set | 1 | 3 |
Carbon steel |
| 5 |
Refined starch concentration system |
Group | 11 | 66.5 |
Carbon steel |
| 6 |
Automatic vacuum dryer |
set | 1 | 14 | |
| 7 |
Conveyor |
set | 1 | 3 | According to the distance charge |
| 8 |
Interim tank |
||||
| Third | Dry section | ||||
| 1 | Air dryer | Set | 1 | 28 |
Aluminum alloy |
| 2 | Radiator | Set | 1 |
Carbon steel |
|
| 3 | Starch screen | Set | 1 |
Carbon steel |
|
| 4 | Distribution Cabinet | Set | 1 | ||
| 5 | A ton of boiler | Set | 1 | ||
| Fourth | Aid machine | ||||
| 1 | Power line | ||||
| 2 | Packing machine | 1 | |||
| 3 | Pipelined and pump/motor | 3 | |||
| 4 | Non-standard parts and other materials | 2 | |||
| 5 | Distribution Cabinet | Set | 3 | ||
| 6 | To guide the design and debug |
