Fruit jams are generally made from larger fruits, such as apples, plums, peaches or grapes. A chutney is a pungent relish of Indian origin made of fruit, spices and herbs. Although originally intended to be eaten soon after production, modern chutneys are often made to be sold, so require preservatives – often sugar and vinegar – to ensure they have a suitable shelf life. Mango chutney, for example, is mangoes reduced with sugar. Where can I get a Commercial Equipment For Making Jam and Chutney? Today we are going to introduce this Multi-purpose Commercial Jam and chutney Making Machine.This Commercial Equipment For Making Jam and Chutney is colloid grinder, made of stainless steel, which can accord to users' special requirement offer the one multi-functional but idling type operation. The machine is sealed and has not kept in touch with the medium definitely,superfine processing mills for grinding wet materials.
Colloid grinder is consisted of the grinding head components, the base transmission components, motor parts of three parts. The materials used in contact with all parts made of high quality stainless steel, static and dynamic grinding is a key component of the machine, according to the nature of the material being processed, grinding the tooth profile is different, but the materials are made of stainless steel tool steel. Motor according to the needs of colloid mill special design, and in the motor flange cover to install retaining disk, to prevent leakage.
Installation and usage of Commercial Equipment For Making Jam and Chutney :
1, In horizontal installations, the designated side must be positioned "up".
2, Check the tightening screws are tightened (rotor center screw is M12 left screw).
3, Before using, with a special wrench to rotate the rotor, check with the stator is in contact, whether stuck phenomenon, if the above situation does not allow boot.
4. Check and connect the power cord (three-phase AC, voltage 380V, body protection ground) and note that the rotor should rotate in the same direction as the arrow on the base (clockwise).
5, Connected to cooling water, and pay attention to the water inlet and outlet signs.
6, Start the motor, the first point to move the switch to check for noise, vibration. If the situation is not normal should immediately stop, troubleshooting and then try to run.
7, After cleaning the stator, rotor residual material should be running in the state, the first large chuck to counterclockwise rotation of not less than 90 ° after the cleaning.
8, How to adjust the stator,totor (adjustment should be carried out in the running state):
A, Loosen the two handles b, move the handle to drive the big chuck rotation, the gap adjustment, positioning disk clockwise rotation gap narrowing, material grain size smaller. Counterclockwise rotation gap increases, coarse grain size.
C, After adjusting the stator and totor, you should also tighten the two handles (clockwise).
D, according to the size of processing materials and batch size requirements, select the best set, the rotor clearance can be adjusted after the limit screw to limit the purpose.
9, Oil should be regularly added into the oil cup.
