Features
Function of Ethiopia Spring Roll Making Machine:
Ethiopia injera making machine mainly used to make the spring roll, the crepe, and can also make the fillo pastry. Zelalem injera machine can make different shape of round shape and the quadrate,etc.
Automatic Injera making machine|Spring Roll Making Machine also called pring roll sheeter machine, crepe, chapatti manufacturing machine.Mainly used to make the spring rolls sheet, egg crepe, ethiopian injera and can also make the Fillo Pastry.
The working process of commercial injera making machine:
The dough is prepared according to the requirements of the dough making process. After the dough is heated and baked by the round baking wheel, it becomes a fixed thickness spring roll or other sheet-like food.
Process or injera making machine: Put the mixed dough into the dough bucket. When the baking wheel is heated to about 150-160 ° C (the temperature control table shows the temperature), start the slurry pump to send the slurry to the nozzle, and operate the clutch lever. The surface paste is adhered to the arc surface of the roasting wheel. When the roasting wheel rotates over the angle of 270-300 degrees, the dough is matured and automatically separated from the roasting wheel to form a fixed thickness spring roll, which is cut into squares after being cut by the cutting machine. , you can fold it for sale, or roll it up immediately.
Spring Roll Making Machine Test Video:
Spring Roll Making Machine Test Video:
Technical Data
Model | GGSR400-6X | GGSR400-6F | GGSR400-6Y |
Diameter of baking part | 600mm | 600mm | 600mm |
Width of dough sheet |
400mm (can be customized according to customer requirements) |
400mm (can be customized according to customer requirements) |
400mm (can be customized according to customer requirements) |
Speed/Capacity | 230m/h (adjustable) | 230m/h (adjustable) | |
Input power | 24KW | 24KW | 23KW |
Heating method | Electric | Electric | Electric |
Components |
Dough sheet forming machine, cooling conveyor, cutting machine, alignment conveyor |
Dough sheet forming machine, cooling conveyor, cutting machine | Dough sheet forming machine, cooling conveyor |
Dimensions | 5000*1300*1500mm | 3500*1300*1500mm | 3000*1300*1500mm |
